QQ-630B Battery Hydraulic Pump Portable Power

Home / Products / Hydraulic Pump / Hydraulic Electric Pump / QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power
QQ-630B Battery Hydraulic Pump Portable Power

QQ-630B Battery Hydraulic Pump Portable Power

The QQ-630B Battery Hydraulic Pump is a high-performance portable hydraulic power unit designed for efficiency, convenience, and safety. Powered by a 40V 5.0Ah lithium battery, it provides long-lasting operation without the need for a socket, making it ideal for mobile and on-site hydraulic tool applications.

Equipped with a shockproof pressure gauge, operators can monitor pressure accurately even in vibration-prone environments. The handboard pressure relief switch allows quick and safe pressure release, while the hydraulic visible oil window ensures optimal oil levels for consistent performance and longevity.

With a high-capacity oil reservoir of 2L and a maximum output pressure of 70 MPa, the QQ-630B efficiently powers a variety of split-type hydraulic tools for cutting, punching, bending, and lifting operations. The 360° quick connector with full copper interface provides reliable and durable connections, reducing downtime during tool changes.

Designed for electric power, chemical industry, steel processing, machinery, and industrial applications, the QQ-630B combines strong power, portability, and safety features in one compact unit. Simple one-click operation and fast battery charging make it a convenient and reliable solution for professional hydraulic tool users.

Net weight: 9.9kg | Gross weight: 15kg | Compact size: 315 × 245 × 405mm

Contact Us
PREV：750W–1.5KW Three Way Hydraulic Electric Pump 700 Bar High Pressure Power PackNEXT：QQ-700B Portable Single Action Hydraulic Pump 220V
  • Specification
  • Contact Us
Model QQ-630B Speed 60KN
High pressure pressure 70Mpa  High voltage flow  0.6L/min
Battery voltage 40V  Battery capacity  5.0Ah
Low pressure pressure 5Mpa  Low voltage flow  3.5L/min
Oil storage capacity 2L  Net weight/gross weight  9.9kg/15kg
Oil species Anti-wear hydraulic oil below 32# or 7-15# hydraulic transmission oil
Packaging size Length 315 × width 245 × height 405mm
